Camshaft Specs
Cam Style: Hydraulic roller, OE roller
Camshaft Use: Street/Strip
Engine Combination: Naturally Aspirated
Camshaft Duration: 229/246
Valve Lift with Factory Rocker Arm Ratio: 0.600 int./0.600 exh.
Lobe Separation (degrees): 110
Intake Centerline: 107
Camshaft Gear Attachment: 3-bolt
Valve Springs Required?: Yes (PAC .660 Dual Valve Spring)
Desired Compression ratio for cam: 10.1+
Aftermarket Stall Converter Required?: Yes, 3200+
Upgraded Rear Gear Required: 3.42+
Operating RPM Range: 2000-7000
Estimated Power Increase: 80+
Head Type: Rectangle Port Heads
Drivability: Excellent midrange to top end HP. Can be daily driven with the proper tune. Heavy chop that will get you noticed!
