Camshaft Specs
Cam Style: Hydraulic roller, OE roller
Camshaft Use: Street/Strip
Engine Combination: Naturally Aspirated
Camshaft Duration: 233/240
Valve Lift with Factory Rocker Arm Ratio: 0.629 int./0.600 exh.
Lobe Separation (degrees): 108
Intake Centerline: 106
Camshaft Gear Attachment: 3-bolt
Valve Springs Required?: Yes (TSP Dual .660 Valve springs)
Desired Compression ratio for cam: 10.5:1+
Aftermarket Stall Converter Required?: Yes, 3600+
Upgraded Rear Gear Required: 3.42+
Operating RPM Range: 2300-7000
Estimated Power Increase: 65+
Fit Stock Untouched Heads: Yes, No Piston to Valve Clearance issues, but measuring is always recommended for any cam installation.
Drivability: Can be daily driven with good tuning down low and a proper sized torque converter to be daily-able in automatics. Manuals will need more thorough tuning. Mostly recommended for a weekend warrior cam on stock cubic inch applications.
