These RC Engineering 750cc Low Resistance, Peak and Hold fuel injectors are flow matched and will fit every model, engine, type or style for the following vehicles:
1992-1995 Honda Prelude
Part # PL9-750
Included: 4 Honda style injectors, spacers/o-rings, and flow sheets. The photo is an example of a similar set.
Note:
1) OBD1 style injector clips are
REQUIRED. If your vehicle still has the stock injector clips and needs OBD1 style injector clips, please select them from the drop down menu above - additional $19.95.
Size Calculation
To determine what size injectors you should use, please visit :
RC Engineering's Technical Notes
Specifications
Flow Rate in CC per minute: 750CC/min @ 43.5 PSI
Flow Rate in LB per hour: 71LBS/HR @ 43.5 PSI
Resistance: 2.5 ohms
Voltage: 8-15 Volts, nominal 13.5 Volts
Amperage: Peak 4.0 Amps/ Hold 1.5 Amps
Pressure: Min 30PSIG/ Max 100PSIG
Part Number: PL9-750
Spacers/O-rings Included: YES
Warranty:
1 year warranty!
