Specifications
Color: Shiny
Ignition Type: Universal
Injector Size: 100 lb/hr @ 58.5 PSI
Max Horsepower Rating: 650 Naturally Aspirated & 600 For Forced Induction Applications
Product Type: EFI System
Part Number: 550-1011
Features:
Bolt on 4150 Flange Carburetor Replacement
Supports up to 650HP with Four 100lb/hr Injectors
Terminator X Max Stealth 4150 kits provide transmission control for Pre-2009 GM 4L60E/4L80E Transmissions (Part numbers 550-1011, 550-1012,550-1013)
Internal 1bar MAP sensor, built into the Terminator X ECU.
All of the wiring exits below the rear fuel injector cover, for a completely stealth installation
Timed spark part for vacuum advanced distributors located under the front fuel bowl, for easy access to the distributor
Air entry is machined to fit most stock style air cleaners with air cleaner locator provisions
External fuel pressure regulator required, set to a base pressure of 58.5 PSI, such as Holley part # 12-886
Integrated ignition timing control improves idle stability, fuel economy, and wide open throttle performance
High Resolution Full Color Touchscreen for Initial Setup, Tuning, and Gauge Displays
Simple Calibration Wizard (answer a few questions about your engine and it creates the base map, then starts tuning on its own!) - NO laptop required
The included Genuine Bosch LSU 4.9 Wideband Oxygen Sensor provides real-time Fuel Map Learn
OEM Style TPS/IAC for years of dependable service
not covered by emissions regulations.
