Specs:
Current Draw: .7 Amp per 1,000 RPM
EO Number: D-115-21
Primary Voltage: 535 Volts
RPM Range: 12,500 RPM with 14.4 Volts
Secondary Voltage: 45,000 Volts
Spark Energy: 135 mJ per spark
Voltage Required: 12-18 Volts, Negative Ground
Warranty: Limited 1 Year Warranty
Features:
Advanced features allow for use in street and racing applications
PC Programmable with easy-to-use Windows based Pro-Data +Software
Plot a boost timing map with 0.1° per psi accuracy
Programmable 3-Step Rev Limiter (100 RPM increments)
Step retard for nitrous applications plus a boost timing map
Capacitive Discharge technology for fast rise time and maximum spark energy
EO # D-115-21
Emissions
This part is legal for sale and use on Emissions Controlled Vehicles, in all 50 states, when used in accordance with the manufacturers application guide because it has a California Air Resources Board (CARB) Executive Order (EO) number.
The following vehicles are considered Emissions Controlled Vehicles:
1966 and newer U.S. manufactured California Certified vehicles
1968 and newer U.S. manufactured Federally Certified vehicles
1968 and newer Foreign manufactured vehicle
