Features:
Built-in Pump: Renowned for setting the bar in fuel delivery systems. Depend on it for consistent performance
Advanced 100 Micron Pre-Filter: Safeguard your engine with our meticulously designed pre-filter. It’s your first line of defense against contaminants, keeping your fuel pure and your system protected
Precision Fuel Sending Unit with attached float arm: Monitors the fuel level with pinpoint accuracy
Designed for EFI or carbureted systems
Maximum continous operating pressure should not exceed 70 psi
Fuel pump utilizes AN-8 ORB style for the outlet and -08 ORB for the return ports.
Ports are not pipe thread and utilize no thread sealant
| A1000 Fuel Pump Power Specs: | ||||
| CARB or EFI | Power Adder | Fuel | Min HP | Max HP |
| Fuel Injected | Forced Induction | Gas | 600 | 1000 |
| Carbureted | Naturally Aspirated | Gas | 800 | 1500 |
| Fuel Injected | Naturally Aspirated | E85 | 500 | 910 |
| Fuel Injected | Naturally Aspirated | E85 | 600 | 1050 |
| Fuel Injected | Naturally Aspirated | Gas | 720 | 1300 |
| Carbureted | Forced Induction | Gas | 700 | 1200 |
| Carbureted | Forced Induction | E85 | 500 | 840 |
| Fuel Injected | Forced Induction | E85 | 400 | 700 |
