Features:
Lighter than the traditional A1000 pump.
Reduced current draw at higher, EFI pressures.
Extended service life in methanol and ethanol.
Integral, external brushless controller for a clean installation, cooler fuel, and enhanced reliability.
Quieter than the traditional A1000 pump.
ORB-10 inlet and outlet ports.
Requires straight 12-VDC to the 16-VDC power supply.
Not compatible with pulse-modulated systems or fuel pump speed controllers.
Includes 2 ea. P/N 12703 stainless steel t-bolt clamps for mounting.
| A1000 Fuel Pump Power Specs: | ||||
| CARB or EFI | Power Adder | Fuel | Min HP | Max HP |
| Fuel Injected | Forced Induction | Gas | 600 | 1000 |
| Carbureted | Naturally Aspirated | Gas | 800 | 1500 |
| Fuel Injected | Naturally Aspirated | E85 | 500 | 910 |
| Fuel Injected | Naturally Aspirated | E85 | 600 | 1050 |
| Fuel Injected | Naturally Aspirated | Gas | 720 | 1300 |
| Carbureted | Forced Induction | Gas | 700 | 1200 |
| Carbureted | Forced Induction | E85 | 500 | 840 |
| Fuel Injected | Forced Induction | E85 | 400 | 700 |
