Features:
Lighter than the traditional external mount pumps.
Reduced current draw at higher, EFI pressures.
Extended service life in methanol and ethanol.
New integral spur-gear pumping mechanism.
60-PSI continuous operating pressure and up to 100-PSI peak pressure, base plus boost.
Integral, external brushless controller for a clean installation, cooler fuel, and enhanced reliability.
ORB-12 inlet and ORB-10 outlet ports.
Requires straight 12-VDC to the 16-VDC power supply.
Not compatible with pulse-modulated systems or fuel pump speed controllers.
This product is not legal for sale or use on emission-controlled vehicles except when used as a direct replacement part matching OEM specifications.
| 7 GPM Fuel Pump Power Specs: | ||||
| CARB or EFI | Power Adder | Fuel | Min HP | Max HP |
| Fuel Injected | Forced Induction | E85 | 1638 | 2380 |
| Fuel Injected | Naturally Aspirated | Gas | 3060 | 4800 |
| Carbureted | Forced Induction | Gas | 2430 | 3800 |
| Carbureted | Naturally Aspirated | E85 | 2268 | 3780 |
| Carbureted | Naturally Aspirated | Gas | 3240 | 5400 |
| Carbureted | Forced Induction | E85 | 1701 | 2400 |
| Fuel Injected | Forced Induction | Gas | 2340 | 3400 |
| Fuel Injected | Naturally Aspirated | E85 | 2142 | 3360 |
