Features:
Proven performance, powering some of the world's fastest EFI vehicles.
Compact size facilitates easy mounting.
Billet aluminum CNC-machined body, not 'cast'.
This product is not legal for sale or use on emission-controlled vehicles except when used on a dedicated race vehicle.
ORB-10 inlet and outlet ports.
For EFI applications use regulator P/N 13145, 13134.
Carbureted gasoline applications require regulator P/N 13202 or P/N 13212.
Alcohol carbureted applications require Double Adjustable Regulator P/N 13209 or 13214.
1/2" Drive Shaft with 1/8" key.
Bracket and Cog Pulley sold separately.
Available as a kit (P/N 17140) includes: Pump, Bracket and Pump Pulley.
Max Fuel Pump HP Output:
Fuel injected engines: GAS
up to 3800 FWHP – naturally aspirated
up to 2920 FWHP – forced air induction
Carbureted engines: GAS
Up to 3900 FWHP – naturally aspirated
Up to 3020 FWHP – forced air induction
Fuel injected engines: E85
up to 2710 FWHP – naturally aspirated
up to 2110 FWHP – forced air induction
Carbureted engines: E85
Up to 2810 FWHP – naturally aspirated
Up to 2210 FWHP – forced air induction
Fuel injected engines: METHANOL
up to 1,450 FWHP – naturally aspirated
up to 1000 FWHP – forced air induction
Carbureted engines: METHANOL
Up to 1,550 FWHP – naturally aspirated
Up to 1050 FWHP – forced air induction
