Features:
E85 Compatible, reduce max FWHP by 30%
Lighter than the traditional external mount pumps.
Reduced current draw at higher, EFI pressures.
Extended service life in methanol and ethanol.
New integral spur-gear pumping mechanism.
60-PSI continuous operating pressure and up to 100-PSI peak pressure, base plus boost.
Integral, external brushless controller for clean installation, cooler fuel and enhanced reliability.
ORB-12 inlet and ORB-10 outlet ports.
Requires straight 12-VDC to 16-VDC power supply.
Not compatible with pulse modulated systems or fuel pump speed controllers.
| 10 GPM Fuel Pump Power Specs: | ||||
| CARB or EFI | Power Adder | Fuel | Min HP | Max HP |
| Carbureted | Forced Induction | Gas | 3420 | 5500 |
| Carbureted | Forced Induction | E85 | 2160 | 3850 |
| Carbureted | Naturally Aspirated | Gas | 4860 | 7600 |
| Fuel Injected | Naturally Aspirated | E85 | 3024 | 4830 |
| Carbureted | Naturally Aspirated | E85 | 3402 | 5300 |
| Fuel Injected | Forced Induction | Gas | 3060 | 4900 |
| Fuel Injected | Forced Induction | E85 | 2142 | 3430 |
| Fuel Injected | Naturally Aspirated | Gas | 4320 | 6900 |
